Fully Automatic Plate Making Machine

Fully Automatic Plate Making Machine

Product advantages:
• Support 1 Bit TIFF,Gerber 274x,DXF and other file formats
• Ultra-long service life of more than 30,000 hours and no attenuation for 10,000 hours
• Quick installation

Availability:

Quantity:



Inquire Add to Basket

Model:
GTS
Brand:
KETCHVIEW
Code:
8442302900

Product Description

Product Description

GTS Fully Automatic Plate Making Machine which is suitable for PCB single-layer pattern printing, legend printing, solder mask printing

Product advantages:
• Support 1 Bit TIFF,Gerber 274x,DXF and other file formats
• Ultra-long service life of more than 30,000 hours and no attenuation for 10,000 hours
• Quick installation

Model	GTS8012	GTS1015	GTS1216
Maximum image output	800*1200 mm	1000*1500mm	1200*1600mm
Maximum frame size	1100*1700 mm	1350*2000mm	1350*2000mm
Frame installation mode	Pneumatic clamp, vertical	Pneumatic clamp, vertical	Pneumatic clamp, vertical
Exposure light source	405nm laser	405nm laser	405nm laser
Number of laser modules	128	160	192
Rated power	800 w	1000w	1000w
Noise	70 db	74db	74db
Interface type	USB2.0/3.0	USB2.0/3.0	USB2.0/3.0
Resolution	847/1270/2540 dpi	847/1270/2540 dpi	847/1270/2540 dpi
Repetitive error	Less than 0.1 mm	Less than 0.1 mm	Less than 0.1 mm
Type of photosensitive adhesive	Most kinds of emulsion	Most kinds of emulsion	Most kinds of emulsion
Photosensitive adhesive thickness	Maximum 1000 μm	Maximum 1000 μm	Maximum 1000 μm
Output speed	Less than 2.5 minutes	Less than 3.5 minutes	Less than 3.5 minutes
